3G modem(7.2 mbps)

Our Unlocked 3G USB MODEM FOR BSNL/MTNL/AIRTEL/AIRCEL.Simply insert 3G SIM card from BSNL/MTNL/AIRTEL/AIRCEL into the modem and get upto 7.2BPS Download and 384KBPS Upload speed

The HSDPA Modem is a complete 3.5G enabled wireless USB Modem designed to offer high-speed wireless connectivity for Windows notebook and desktop computers on HSDPA networks. It is easy to use USB connector and the ability to roam globally on 2100M UMTS and quad-band GSM/ EDGE networks.It enables connection to internet downlink speed up to 7.2Mbps and uplink to 384kbps

The compact USB Modem don’t need to install drivers from a CD because the software is included on the device. It also supports a microSD memory expansion no matter whether connect with the Internet or not .



Basic performance

* Worldwide use with tri-band UMTS and quad-band GSM/ EDGE operation.
* Capable of wireless data speed up to 7.2Mbps

* Receive SMS messages.
* Accessing E-mail and browsing the WEB.
* USIM card and SIM functionality.
* MicroSD memory expansion.
* Zero install software,No CD required for windows.



Features



Dimension:  89.1*27.6*12.7mm



Weight:  About 21g



Language:  English, Chinese



Mode:  Dual mode



Driver installation: Zero install software, No CD required for windows.



Availble operation system:

Windows2000/XP/VISTA/win7/Linux MAC lastest OS 10.4 and 10.5



External Interface:
USB 2.0 interface with PC
Internal Antenna Built-in 5 bands
SIM card slot and MicroSD memory expansion slot, supports 8GB memory card.





Workable network and RF band

Quad band GSM/GPRS/EDGE:  850/900/1800/1900MHz

Tri-band UMTS:  2100 MHz



Transmission rate of differetnt network

     HSUPA:  Max uplink, 5.76Mbps, Max Downlink: 7.2Mbps

     HSDPA :  Max downlink:7.2Mbps uplink:384Kbps

     WCDMA:  Downlink 3.6Mbps Uplink 384Kbps

     EDGE: Max downlink: 384Kbps

     GPRS: Max downlink: 247Kbps



Function of phonebook:

build New, edit and delete, Store and send



SMS functions:

Group and single sending , reply, Create new,delete,edit, Save to draft box, Sms shift between SIM card and PC



System Requirements:
Card Slots: USB Interface
Memory: 32 MB
Disk Space: 32 MB
System:Pentium 150MHz or higher





Enviroment requirement

Working temperature: -20°c ~ +55°c

Storage temperature: -20°c ~ +60°c

Humidity : 0%~90% (35°c)
